ELECTROSTATICS InteGREATed conductive suit
The ELECTROSTATICS InteGREATed conductive suits protect the worker from:
- Harmful AC electric fields
- Electrical discharge during live work
- Current shock from induced voltages
- Thermal protection from electric arc
All the ELECTROSTATICS products are based on the InteGREATed protection features. To provide full protection during the work, please, choose those products that match your activity fields.
Bare-hand
conductive suit
Working live in the energized grid with proper face protection (first in the world).
AC Induction
conductive suit
Working in the vicinity of energized AC electrical installations. The garment can shunt currents up to 50 A without any damage for the wearer.
Radiofrequency (RF)
conductive suit
Personal protective equipment (PPE) against the harmful impacts of electromagnetic radiation.
The special combination of the mentioned conductive suits is also possible.
InteGREATed protection – the basis of all ELECTROSTATICS product
Protection against:
- Harmful AC electric fields
- Electrical discharge during live work
- Current shock from induced voltages
- Thermal protection from electric arc
Fabric system
The double-sided material of this single-layer clothing is unique: The combination of silver-coated threads and a grid of steel stainless yarn shields high electric fields almost completely while the insulating of the inner surface of the fabric uncouples the metalized surface from the human body to provide previously unattainable comfort. This flame-retardant and arc protective material are resistant to multiply washing and human sweat and also has outstanding breathability.
Upper layer provides protection against thermal hazards of an electric arc and ignition caused by spark discharge.
Highly conductive band has got electric resistance not more than 0,1 Ohm/m and can shunt currents up to 35 A without any damage.
Conductive double-sided fabric is a unique material which combines two inseparable surfaces: conductive (steel-silver) and insulating (meta aramid-FR viscose). Such a combination ensures maximum protective features and optimum level of comfort during work. Electric resistance of the conductive surface of the fabric is is not more than 2 Ohm.
Technical information
Electric resistivity of the conductive garment, not more than
IEC 60895:2020
1 Ohm
Shield factor at 50 Hz frequency, not less than
IEC 60895:2020
70 dB
Arc Thermal Performance Value (IEC 61482)
Conductive garment
11 cal/cm2*
*This ATPV value can be increased with accesories, for more information, please check the Bare-hand conductive suit subpage.
Single Piece Set
inteGREATed protection
- A conductive shielding coverall with a hood (head cover) and a face mesh (only for Bare-hand conductive suit).
- A conductive shielding jacket with a hood (a head cover)
- A conductive shielding bib-and-brace
- Conductive shielding gloves
- Conductive shielding socks
- Two removable equipotential bonding leads with clamps (only for Bare-hand conductive suit)
- ATPV level – 11 cal/cm2
Double Pieces Set
inteGREATed protection
- A conductive shielding jacket with a hood (head cover) and a face mesh only for Bare-hand conductive suit
- Conductive shielding bib-and-brace or conductive shielding trousers
- Conductive shielding gloves
- Conductive shielding socks
- Two removable equipotential bonding leads with clamps only for Bare-hand conductive suit
- ATPV level – 11 cal/cm2
Equipotential bonding leads between jacket and bib-and-brace or trousers
Equipotential bonding leads between jacket and gloves
Equipotential bonding leads between bib-and-brace and boots
Technical information
Electric resistivity of the conductive gloves, not more than IEC 60895:2020
30 Ohm
Electric resistivity of the conductive socks, not more than IEC 60895:2020
30 Ohm
Both sets provides protection against
- a harmful impact of the electric field of industrial frequency; electrical discharges while bare-hand working with live-parts;
- a harmful impact of air ions (including extra heavy air ions – aerosols)
- a current shock of an induced voltage
- a thermal hazards of an electric arc.
Bare-hand conductive suit
The basis of the Bare-hand conductive suit is the ELECTROSTATICS inteGREATed protection
The Bare-hand conductive suit is intended to be worn during live working (especially bare-hand working) with AC and DC electrical installations.
The sets provides protection against
- a harmful impact of the electric field of industrial frequency;
- electrical discharges while bare-hand working with live-parts;
- a harmful impact of air ions (including extra heavy air ions – aerosols)
Main feature of the set besides the inteGREATed protection set – face protection
Several studies have shown that face mesh is an essential component to protect the most sensitive parts of the body. ELECTROSTATICS was the first company that realizes the importance of face protection, and due to this, this accessory is a mandatory component of all ELECTROSTATICS Bare-hand conductive suits.
Bare-hand conductive suit set is available in Single Piece Set and also in Double Pieces Set
Single Piece Set
inteGREATed protection
- A conductive shielding coverall with a hood (head cover) and a face mesh.
- A conductive shielding jacket with a hood (a head cover)
- face mesh (only for Bare-hand conductive suit)
- A conductive shielding bib-and-brace
- Conductive shielding gloves
- Conductive shielding socks
- Two removable equipotential bonding leads with clamps
- ATPV level – 11 cal/cm2
Double Pieces Set
inteGREATed protection
- A conductive shielding jacket with a hood (head cover) and a face mesh (only for Bare-hand conductive suit)
- Conductive shielding bib-and-brace or conductive shielding trousers
- face mesh (only for Bare-hand conductive suit)
- Conductive shielding gloves
- Conductive shielding socks
- Two removable equipotential bonding leads with clamps
- ATPV level – 11 cal/cm2
Accessories might be ordered separately
Extra conductive gloves
Conductive winter boots
Conductive boots
Additional winter accessories are also available for the Bare-hand conductive suit
winter accessories
Cold-proof mittens and leather boots
Winter accessories can also increase the arc protection of the conductive set!
Jacket and bib-and-brace with detachable warm-up undercoat and inner trousers have been developed to be worn at low temperatures under severe climate conditions
Technical information
Arc Thermal Performance Value (IEC 61482)
Conductive garment
11 cal/cm2
Conductive garment + Nomex upper suit
22.4 cal/cm2
Conductive garment + winter lining + Nomex upper suit
78 cal/cm2
Nomex upper suit
8 cal/cm2
Nomex upper suit with winter lining
64 cal/cm2
AC Induction conductive suit
The basis of the AC Induction conductive suit is the ELECTROSTATICS inteGREATed protection
Conductive clothing against induced voltage and induced current
The AC Induction conductive suit functions as an additional protection in case of not proper grounding in a vicinity of energized AC electrical installations.
The AC Induction conductive suit in case of emergency may restore or create equipotentiality between conductive parts at the workplace.
The product meets the requirements of the following standards and regulations:
- OSHA 1910.269
- IEC 60895:2002
- IEC 61482:2009
- ASTM
- IEEE 1067-2002
AC Induction conductive suits are intended to be worn when:
Working on discharged power lines under the electromagnetic influence of the operating AC electrical installations.
Working on AC electrified railway lines including lightning protection cables, suspension metal ropes, communication wires, etc.
With using the AC Induction conductive suit the injuries caused by induced currents can steadly decrease to almost zero.
The sets provides protection against
Protection against the current shock of the induced voltage. It prevents current through the worker’s body to exceed 6 mA (the let-go limit) while the induced current flowing through.
Main feature of the set besides the inteGREATed protection set – highly conductive tape and garment
Highly conductive tape implemented to the suit has got electrical resistivity of not more than 0.1 Ohm/m and can conduct current up to 100 A for more than 2 minutes without breaking electrical continuity.
Electric resistance of the conductive garment is not more than 1 Ohm. Protection against arc flash with the ATPV level of 11 cal/cm2. Protection against harmful impact of the electric field of industrial frequency.
AC induction conductive suit set is available in Single Piece Set and also in Double Pieces Set
Single Piece Set
inteGREATed protection
- A conductive shielding coverall with a hood (head cover)
- Conductive shielding gloves
- Conductive shielding socks
- ATPV level – 11 cal/cm2,
Double Pieces Set
inteGREATed protection
- A conductive shielding jacket with a hood (head cover)
- Conductive shielding bib-and-brace or conductive shielding trousers
- Conductive shielding gloves
- Conductive shielding socks
- ATPV level – 11 cal/cm2
Accesories for AC induction conductive suit
Accessories might be ordered separately
Extra conductive gloves
Conductive winter boots
Conductive boots
Radio-frequency (RF) conductive suit
The basis of the Radiofrequency (RF) conductive suit is the ELECTROSTATICS inteGREATed protection
RF suits are intended to be worn when working near:
- operating radio transmitters
- antenna-feeder systems
- radio stations
- television transmitters
- cellular and satellite communication systems
- other EMI sources of 30 kHz – 60 GHz radiofrequency range.
The sets provides protection against
The Radiofrequency (RF) conductive suit is intended to be worn harmful impacts of electromagnetic radiation are present.
Main feature of the set besides the inteGREATed protection set – electrically conductive sheath around the human body.
The protection principle is based on reducing the electromagnetic field’s intensity inside the clothing down to the safe level by creating a closed electrically conductive sheath – a faraday cage – around the human body.
The Radiofrequency (RF) conductive suit set is available in Single Piece Set.
